High Pressure Metering Pumps


Home>Products

Our line of ReciPro Optos and ReciPro HP Series metering pumps meet the industry’s exacting requirements for precision, reproducibility and pressure. The Pico Tag H/D Workstation provides an easy-to-use system for the hydrolysis and derivatization of samples before amino acid composition analysis. Additionally, We offer a wide selection of off-the-shelf metering pumps and customize them to meet the needs of OEMs.

Our pumps and instrumentation are ideally suited for benchtop, pilot-plant, and OEM applications, including:

  • Chemical feed
  • Flow chemistry
  • Industrial process
  • HPLC
  • Supercritical CO2
  • Post column reaction



Use the product selector below to filter the ideal product for your application.

  • 1HI
    • 1HI

    • 1HI

      • Type - Optos Series
      Flow - 0.01-20mL/min
      Pressure - 3000 psi (200 bar)
      Material - PEEK
      Explosion - N
  • 1HM
    • 1HM

    • 1HM

      • Type - Optos Series
      Flow - 0.01-20mL/min
      Pressure - 3000 psi (200 bar)
      Material - 316SS
      Explosion - N
  • 1HMH
    • 1HMH

    • 1HMH

      • Type - Optos Series
      Flow - 0.01-20mL/min
      Pressure - 3000 psi (200 bar)
      Material - Hastelloy-C
      Explosion - N
  • 1LI
    • 1LI

    • 1LI

      • Type - Optos Series
      Flow - 0.002-2.5mL/min
      Pressure - 4000 psi (275 bar)
      Material - PEEK
      Explosion - N
  • 1LIP
    • 1LIP

    • 1LIP

      • Type - Optos Series
      Flow - 0.002-2.5mL/min
      Pressure - 4000 psi (275 bar)
      Material - PEEK
      Explosion - N
  • 1LM
    • 1LM

    • 1LM

      • Type - Optos Series
      Flow - 0.002-2.5mL/min
      Pressure - 6000 psi (410 bar)
      Material - 316SS
      Explosion - N
  • 1LMP
    • 1LMP

    • 1LMP

      • Type - Optos Series
      Flow - 0.002-2.5mL/min
      Pressure - 6000 psi (410 bar)
      Material - 316SS
      Explosion - N
  • 1SI
    • 1SI

    • 1SI

      • Type - Optos Series
      Flow - 0.003-5.0mL/min
      Pressure - 4000 psi (275 bar)
      Material - PEEK
      Explosion - N
  • 1SIP
    • 1SIP

    • 1SIP

      • Type - Optos Series
      Flow - 0.003-5.0mL/min
      Pressure - 4000 psi (275 bar)
      Material - PEEK
      Explosion - N
  • 1SM
    • 1SM

    • 1SM

      • Type - Optos Series
      Flow - 0.003-5.0mL/min
      Pressure - 6000 psi (410 bar)
      Material - 316SS
      Explosion - N
  • 1SMH
    • 1SMH

    • 1SMH

      • Type - Optos Series
      Flow - 0.003-5.0mL/min
      Pressure - 6000 psi (410 bar)
      Material - Hastelloy-C
      Explosion - N
  • 1SMP
    • 1SMP

    • 1SMP

      • Type - Optos Series
      Flow - 0.003-5.0mL/min
      Pressure - 6000 psi (410 bar)
      Material - 316SS
      Explosion - N
  • 2HI
    • 2HI

    • 2HI

      • Type - Optos Series
      Flow - 0.02-40mL/min
      Pressure - 1500 psi (100 bar)
      Material - PEEK
      Explosion - N
  • 2HM
    • 2HM

    • 2HM

      • Type - Optos Series
      Flow - 0.02-40mL/min
      Pressure - 1500 psi (100 bar)
      Material - 316SS
      Explosion - N
  • 2HMH
    • 2HMH

    • 2HMH

      • Type - Optos Series
      Flow - 0.02-40mL/min
      Pressure - 1500 psi (100 bar)
      Material - Hastelloy-C
      Explosion - N
  • 2LI
    • 2LI

    • 2LI

      • Type - Optos Series
      Flow - 0.003-5.0mL/min
      Pressure - 4000 psi (275 bar)
      Material - PEEK
      Explosion - N
  • 2LIP
    • 2LIP

    • 2LIP

      • Type - Optos Series
      Flow - 0.003-5.0mL/min
      Pressure - 4000 psi (275 bar)
      Material - PEEK
      Explosion - N
  • 2LM
    • 2LM

    • 2LM

      • Type - Optos Series
      Flow - 0.003-5.0mL/min
      Pressure - 6000 psi (410 bar)
      Material - 316SS
      Explosion - N
  • 2LMP
    • 2LMP

    • 2LMP

      • Type - Optos Series
      Flow - 0.003-5.0mL/min
      Pressure - 6000 psi (410 bar)
      Material - 316SS
      Explosion - N
  • 2SI
    • 2SI

    • 2SI

      • Type - Optos Series
      Flow - 0.01-10mL/min
      Pressure - 4000 psi (275 bar)
      Material - PEEK
      Explosion - N
  • 2SIP
    • 2SIP

    • 2SIP

      • Type - Optos Series
      Flow - 0.01-10mL/min
      Pressure - 4000 psi (275 bar)
      Material - PEEK
      Explosion - N
  • 2SM
    • 2SM

    • 2SM

      • Type - Optos Series
      Flow - 0.01-10mL/min
      Pressure - 6000 psi (410 bar)
      Material - 316SS
      Explosion - N
  • 2SMH
    • 2SMH

    • 2SMH

      • Type - Optos Series
      Flow - 0.01-10mL/min
      Pressure - 6000 psi (410 bar)
      Material - Hastelloy-C
      Explosion - N
  • 2SMP
    • 2SMP

    • 2SMP

      • Type - Optos Series
      Flow - 0.01-10mL/min
      Pressure - 6000 psi (410 bar)
      Material - 316SS
      Explosion - N
  • 3HI
    • 3HI

    • 3HI

      • Type - Optos Series
      Flow - .04-80mL/min
      Pressure - 750 psi (50 bar)
      Material - PEEK
      Explosion - N
  • 3HM
    • 3HM

    • 3HM

      • Type - Optos Series
      Flow - .04-80mL/min
      Pressure - 750 psi (50 bar)
      Material - 316SS
      Explosion - N
  • 3HMH
    • 3HMH

    • 3HMH

      • Type - Optos Series
      Flow - .04-80mL/min
      Pressure - 750 psi (50 bar)
      Material - Hastelloy-C
      Explosion - N
  • 3LI
    • 3LI

    • 3LI

      • Type - Optos Series
      Flow - 0.01-10mL/min
      Pressure - 3000 psi (200 bar)
      Material - PEEK
      Explosion - N
  • 3LM
    • 3LM

    • 3LM

      • Type - Optos Series
      Flow - 0.01-10mL/min
      Pressure - 3000 psi (200 bar)
      Material - 316SS
      Explosion - N
  • 3SI
    • 3SI

    • 3SI

      • Type - Optos Series
      Flow - 0.01-20mL/min
      Pressure - 1500 psi (100 bar)
      Material - PEEK
      Explosion - N
